Left side 54 - 57%
Rear 53 - 54%
Cross 64-70%
Left Front Camber 0 - ½ Caster 7.5
Right Front Camber -2 ½ - -3 Caster 11 Toe (L) 0 Toe out ( R ) 1/16
Stagger Front 1 ½ - 1 ⅝ Stagger Rear ¾ - 1 1/2
L 4 ¼ R 4 ½ inch Measure from OUTSIDE (Frame) Rear Cassette to where the wheel meets the hub Note: Older Chassis can use same % just less cross
Rear Hub Placement
JR1 and JR2 Set Up Sheet seventy-nine
PROWLER CHASSIS 79
