PROWLER CHASSIS 79
Senior Stock
RF
LF
LR
RR
Nose 45.5-46.5%
Toe Left Front 0
Toe Right Front
Out 1/16-1/8
Camber Right Front -2.5---3
Caster Right Front 10-13
Camber Left Front 0-+.5
Caster Left Front 7-10
Cross 62 -71%
Left Side 58.5-61%
Rear 53.5-54.5%
Left Front
AIR
LBS
Right Front
AIR
LBS
Race Track
Date
Right Rear Hub
4 ½”
Left Rear Hub
4 ¼”
Right Rear
AIR
LBS
Left Rear
AIR
LBS
Rear Hub Spacing : Measured from the face of the hub where the wheel mates to the hub to the side of the rear bearing cassette
Notes:
Front Stagger 1 1/2
Rear Stagger 3/4-1 1/2
